Nitrile (NBR) Solid Cord – 1.5mm Diameter, 70 ShA x 10m Long
SKU
10R2001106
- Diameter: 1.5mm
- Length: 10m
- Material: Nitrile (NBR) Sponge
- Colour: Black
- Hardness: 70 ShA
- Weight: 0.02kg
- Temperature Range: Min: -30°C, Max: 100°C
Nitrile (NBR) solid cord is a versatile, cost-effective sealing solution renowned for its exceptional resistance to oils, fuels, and a wide range of chemicals, making it ideal for automotive and industrial applications.
- Diameter: 1.5mm
- Length: 10m
- Material: Nitrile (NBR) Sponge
- Colour: Black
- Hardness: 70 ShA
- Weight: 0.02kg
- Temperature Range: Min: -30°C, Max: 100°C
Nitrile (NBR) solid cord is a versatile, cost-effective sealing solution renowned for its exceptional resistance to oils, fuels, and a wide range of chemicals, making it ideal for automotive and industrial applications.
| Tolerance (±mm) | 0.25 |
|---|---|
| Tolerance Hardness (±) | 5 |
| Colour | Black |
| Hardness | 70 ShA |
| Elongation at break (%) | 300 |
| Length (mm) | 10000 |
| Material | Nitrile (NBR) |
| Maximum Temperature (°C) | 100 |
| Minimum Temperature (°C) | -30 |
| Density (g/cm³) | 1.3 |
| Compression Set Testing Parameters | 22hrs @ 100°C |
| Diameter (mm) | 1.5 |
| Cross Section Type | Circular |
| Compression Set (%) | 18 |
| Tensile Strength | 12 MPa |
| Weight (kg) | 0.02 |
*Dimensions can vary, they are typical only.
Write Your Own Review
| Product Datasheet | 10R2001106-Nitrile_NBR_Solid_Cord_1.5mm_Dia_70_ShA_10m_long.pdf |
|---|
