£356.60
£297.17
Electrically Conductive Solid Silicone Sheet - 915mm Wide x 0.8mm Thick, Black, 65 ShA
SKU
3043944
- Width: 915mm x Length: 1m (up to 12.2m) x Thickness: 0.8mm
- Material: Silicone (VMQ)
- Hardness: 65 ShA
- Colour: Black
- Density: 1.17g/cm³
- Electrical Conductivity: 5 ohm-cm
- Weight: 0.86kg per Linear Metre
- Temperature Range: Min: -62°C, Max: 225°C
Electrically conductive silicone sheet provides superior EMI/RFI shielding, ESD protection, and low amperage conduction. Flame retardant and flexible, it's ideal for medical devices, automotive, and consumer electronics.
Electrically Conductive Solid Silicone Sheet - 915mm Wide x 0.8mm Thick, Black, 65 ShA
This specially engineered electrically conductive silicone sheet is the perfect solution for applications requiring superior electromagnetic shielding, electrostatic discharge (ESD) protection, and low amperage conduction.
- Width: 915mm x Length: 1m (up to 12.2m) x Thickness: 0.8mm
- Material: Silicone (VMQ)
- Hardness: 65 ShA
- Colour: Black
- Density: 1.17g/cm³
- Electrical Conductivity: 5 ohm-cm
- Weight: 0.86kg per Linear Metre
- Temperature Range: Min: -62°C, Max: 225°C
Key Benefits
- Electrically Conductive: This silicone sheet is filled with carbon black, allowing it to conduct low electrical amperages efficiently.
- Superior EMI and RFI Shielding: Protects sensitive electronic components from electromagnetic and radio frequency interference, ensuring reliable performance.
- Enhanced ESD Protection: Offers excellent electrostatic discharge protection, preventing potential damage to electronic devices and circuits.
- Flame Retardant: Compliant with stringent safety standards, the silicone material provides an added layer of fire resistance.
- Flexible and Durable: The material is highly flexible, making it suitable for various applications without compromising its durability or performance in harsh environments.
- Pressure Sensitive Adhesive: The silicone sheet is available with an adhesive backing, ensuring easy and quick installation in your projects.
Applications
- Electromagnetic Interference (EMI) Shielding
- Radio Frequency Interference (RFI) Shielding.
- Electrostatic Discharge (ESD) Protection
- Medical Devices
- Automotive Electronics
- Consumer Electronics
- Industrial Equipment
Additional Information
Polymax also provides a fabrication service, enabling the creation of custom gaskets, seals, or strips tailored to your specific requirements.
| Material | Silicone (VMQ) |
|---|---|
| Density (g/cm³) | 1.17 |
| Width (mm) | 915 |
| Length (mm) | 1000 |
| Roll Length (m) | 12.2 |
| Thickness (mm) | 0.8 |
| Tolerance Thickness (±mm) | 0.25 |
| Tolerance Width (±mm) | 27.45 |
| Hardness | 65 ShA |
| Tolerance Hardness (±) | 5 |
| Colour | Black |
| Maximum Temperature (°C) | 225 |
| Minimum Temperature (°C) | -62 |
| Tensile Strength | 5.2 MPa |
| Elongation at break (%) | 260 |
| Compression Set (%) | 26 |
| Compression Set Testing Parameters | 70 h @ 150°C / 25% |
| Weight (kg) | 0.85644 |
| Form | Roll |
*Dimensions can vary, they are typical only. Stated temperature range and approvals do not apply to self adhesive backing.
