DS Concave Buffer/foot Mounting, Ø25mm H18mm M8x20mm, EPDM 60 ShA Standard Steel

The DS Concave Buffer and Foot has a high grip concave surface which ensures stability, while the progressive bump stop design absorbs shocks gradually. Durable and versatile, it's perfect for lathes, CNC machines, and more. Easy to install and cost-effective.

• Mount Type: DS (Male)
• Diameter: 25mm
• Height: 18mm
• Male Bolt Size: M8
• Male Bolt Length: 20mm
• Material: EPDM
• Colour: Grey
• Weight: 0.023Kg

Key Benefits

• High Grip Suction: The concave surface of the DS Concave Mount ensures excellent grip, providing secure and stable isolation even in high-vibration environments.
• Effective Vibration Isolation: Designed to minimise the impact of vibrations, these mounts effectively reduce noise and prevent damage to equipment, increasing longevity and reducing wear on sensitive components.
• Progressive Energy Absorption: The DS Concave Mount design absorbs shocks gradually, ensuring smooth operation and preventing abrupt deceleration that could cause damage to the equipment.
• Durable and Long-Lasting: Constructed to withstand demanding conditions, these mounts offer long-lasting performance, making them a cost-effective solution for vibration isolation in heavy-duty applications.
• Versatile Use: Ideal for applications where equipment cannot be fixed to its environment, allowing for mobility and flexibility while maintaining stability and reducing vibrations.

Applications

• Lathes
• CNC Machines
• Presses
• Laboratory Equipment
• Electric Motors
• Instrumentation and Medical Equipment

Additional Information

• Easy Installation: Designed for ease of use, these mounts can be quickly installed in a variety of equipment without the need for permanent fixing, allowing for mobility and flexibility in different setups.
• Cost-Effective and Long-Lasting: Offering high performance at an affordable price, the DS Concave Mount provides excellent value by extending the lifespan of equipment and reducing the need for maintenance.
• Reliable Performance in High-Impact Applications: Ideal for use in high-impact environments where vibration isolation and energy absorption are essential for protecting machinery and ensuring smooth operation.

EPDM compounds offer excellent resistance to weathering, ozone, and aging, with stable performance across a wide temperature range. They provide outstanding resistance to water, steam, and many polar solvents, as well as brake fluids and phosphate-ester-based hydraulic fluids. EPDM maintains flexibility, resilience, and mechanical strength under thermal and chemical stress. Performs reliably in outdoor, automotive, and industrial applications where long-term durability and resistance to compression set are required.

Temperature Range

• Up to 150°C (Intermittent)
• Down to -45°C
• Recommended temperature range: -40°C to +120°C

Chemical Resistance

Good resistance to:

• Hot water and steam up to 149°C (with special compounds up to 260°C)
• Glycol-based brake fluids (DOT 3 & 4) and silicone-based brake fluids (DOT 5) up to 149°C
• Many organic and inorganic acids
• Cleaning agents, sodium and potassium alkalis
• Phosphate-ester based hydraulic fluids (HFD-R)
• Silicone oil and grease
• Many polar solvents (alcohols, ketones, esters)
• Ozone, aging, and weather resistant

Not compatible with:

• Mineral oil products (oils, greases, and fuels)
