CD Waisted Mount (F/F), Ø70mm Height 53mm M12x12mm, NR 60 ShA Standard Steel

Waisted Bobbin Mounts provide superior vibration isolation with enhanced lateral displacement while maintaining vertical stability. Made from durable rubber, these mounts absorb vibrations effectively, making them perfect for automotive, HVAC, and medical applications. Easy to install and available in various sizes, they ensure reliable performance in demanding conditions.

• Mount Type: CD (Female/Female)
• Diameter: 70mm
• Height: 53mm
• Female Bolt Size: M12
• Female Bolt Depth: 12mm
• Maximum Load Compression: 124Kg
• Maximum Shear Load: 18.6Kg
• Material: Natural Rubber (NR)
• Colour: Black
• Weight: 0.3Kg

Key Benefits

• Enhanced Lateral Vibration Isolation: The waisted design allows for greater lateral displacement, improving vibration absorption in horizontal directions.
• Vertical Stability: Despite the increased lateral deflection, the mount remains securely positioned within the vertical plane, ensuring consistent performance.
• Low Shear Stiffness: The design features low shear stiffness, which improves the mount's ability to absorb vibrations and reduce wear on sensitive components.
• Durable and Reliable: Made from high-quality rubber, these mounts provide long-lasting durability even under demanding conditions.
• Versatile Performance: Ideal for use in a wide variety of applications, offering flexibility in vibration isolation for various machinery and equipment types.

Applications

• Automotive
• Agricultural
• Construction Equipment
• HVAC Systems
• Compressors
• Railway
• Electric Motors
• Renewable Energy
• Generators
• Transportation
• Instrumentation
• Medical
• Laboratory Equipment:

Additional Information

• Customisable Options: Available in different sizes and configurations to meet your specific needs and installation requirements.
• Effective Vibration Isolation: Ideal for machines and equipment that experience lateral movement, ensuring effective reduction of vibration and noise.
• Easy Installation: The mounts are designed for straightforward installation, providing a quick and efficient solution to vibration isolation challenges.

Natural rubber (NR) is a versatile and adaptable material characterised by its ability to accept and recover from large deformations. Unlike steel or other metals, it possesses some inherent damping characteristics and can store a larger amount of elastic strain energy per unit volume, making it ideal for use in dampers or as a rubber spring. Natural rubber compounds have a high tensile strength, long fatigue life, and excellent tear resistance.

Natural rubber compounds also exhibit low hysteresis compared with other rubbers. This results in lower heat buildup during repeated deformations, making it an ideal polymer for vibration isolation. Other mechanical properties such as resistance to fatigue, abrasion, tear, and flex are also generally superior in these compounds compared to synthetic elastomers.

NR compounds are not suitable for applications requiring contact with oil, kerosene, diesel, petrol, or solvents like benzene and toluene. These compounds also exhibit poor oxygen and ozone resistance, although this can be somewhat improved by adding antioxidants.

Should you like to discuss your application further, please call us on +44 1420 474123 for more information.

Temperature Range

• Up to 100°C (Intermittent)
• Down to -25°C

Recommended temperature range: -10°C to +100°C

Chemical Resistance

Good resistance to water swell, dilute acids, dilute alkalis, and alcohol.

Not compatible with:

• Mineral oil products (oils, greases, and fuels)
• Steam
• Aliphatic, halogenated, and aromatic hydrocarbons
• Phosphates
• Concentrated acids and alkalis

For detailed chemical compatibility, please see Chemical Compatibility.
